Programmable Switching & Signal Routing

SMX-8050

A scalable 5 × 8 relay switch matrix for programmable signal routing, channel selection and automated test-fixture reconfiguration across up to 40 switching channels.
Request a Consultation
View Specifications
SMX 8050
Switch Matrix 8X5

5 × 8 Modular Matrix

Five independent eight-channel switching banks
Switch Matrix 1

Up to 40 Switching Channels

High-voltage relay switching

250 VAC Switching

Remote control interface

Remote / Local Operation

Key Specifications

Switch Matrix 8X5

5 × 8 matrix

Five independent banks · 8 channels per bank
Switch Matrix 1

8 / 16 / 24 / 32 / 40

Selectable switching-channel configurations
USB-C UART control

USB-C UART

9600 baud communication interface
SMX 8050

Remote / Local

Operation interface
Maximum switching voltage

250 VAC

Maximum switching voltage
Rated DC relay load

2 A @ 30 VDC

Rated DC load
Rated AC relay load

0.5 A @ 125 VAC

Rated AC load
Relay operate time

≤ 4 ms

Maximum operate time
Relay release time

≤ 4 ms

Maximum release time
Switch Matrix 1

40 channels

Maximum switching capacity
Operation interface

Remote / Local

Operation interface
Programmable switching control

Programmable

Software-controlled channel routing

Flexible Matrix Configuration

  • 8-channel configuration
  • 16-channel configuration
  • 24-channel configuration
  • 32-channel configuration
  • 40-channel configuration

Scale the switching matrix to the fixture

switch

Applications

Switch Matrix 8X5

Automated test-fixture routing

Switch Matrix 1

Multi-device channel selection

Multi-terminal signal routing

Multi-terminal signal routing

Sensor and instrumentation switching

Sensor & instrumentation switching

Automated electrical test platform

Automated measurement systems

Designed for Scalable Test Routing

Electric Darker Neural Brain Icon

Modular Bank Architecture

Use one or more eight-channel banks as the fixture grows.

spec range

Repeatable Switching States

Reproduce channel configurations under software control.

Switch Matrix 8X5

Built-In 5-Bank Switch Matrix

The SMX-8050 organizes 40 relay switching channels into five independent eight-channel banks, allowing the routing architecture to scale with the test fixture.
  • Five independent switching banks
  • Eight relay channels per bank
  • 8 / 16 / 24 / 32 / 40-channel configurations
  • Remote software control with local-operation capability
  • Suitable for AC and DC signal routing
switch
SMX 8050

Signal Routing and Automation

  • Independent bank control
  • Automated channel selection
  • Repeatable fixture reconfiguration
  • Multi-device signal routing
  • AC and DC switching workflows
  • Integration into automated test systems

nV Software Capabilities

  • Channel and bank configuration
  • Remote switching control
  • Routing-state management
  • Sequence-based switching
  • Recipe save and load
  • Terminal-level communication
nV software capabilities

Open and Integrable Platform

USB-C UART communication at 9600 baud supports integration with laboratory and automated-test workflows. Operation can be managed remotely or locally according to the setup.

Supported Applications

Switch Matrix 1

Signal-matrix routing

Multi-terminal device testing

Multi-terminal device testing

Switch Matrix 8X5

Expandable test fixtures

Sensor routing

Sensor & instrumentation routing

Typical Switching Tasks

✓   Channel selection
✓   Signal routing
✓   Device isolation
✓   Bank-by-bank switching
✓   Fixture reconfiguration
✓   Automated switching sequences
✓   Remote / local operation
✓   Multi-device test routing
✓   AC / DC path switching
✓   8-channel operation
✓   16–40 channel expansion
✓   Repeatable routing states
✓   User-defined switching sequences
